DAB ALP 2000 M inline centrifugal pump is designed for individual and collective heating systems, air conditioning lines and hot water circulation. Its inline structure allows direct installation on the pipeline, saving space and helping maintain stable water movement in the system. For users looking for a powerful DAB pump for boiler rooms, heating systems and hot water circulation, this model is a suitable choice.
The pump operates with 1x220-240V power supply and has a maximum power of 750 W. With a maximum flow rate of 9.2 m³/h and a maximum head of 21.1 m, it is effective for small and medium engineering systems. DAB ALP 2000 M is equipped with a two-pole motor running at 2870 rpm.
This model is suitable for high-temperature liquids and can operate with liquid temperatures up to 120°C. IP55 protection class, 10 bar maximum operating pressure and F insulation class support safe and long-term operation. It is a practical and reliable solution for stable circulation in heating, hot water and air conditioning systems.

Features

• Model: DAB ALP 2000 M
• Product type: Inline centrifugal pump
• Working range: 0.2–8.4 m³/h
• Maximum flow rate: 9.2 m³/h
• Maximum head: 21.1 m
• Maximum power: 750 W
• Nominal power P2: 550 W
• Voltage: 1x220-240V
• Nominal current: 3.7 A
• Maximum operating pressure: 10 bar
• Maximum liquid temperature: 120°C
• Protection class: IP55
• Insulation class: F
• Capacitor: 16 µF
• Motor type: 2-pole motor
• Rotation speed: 2870 rpm
• Suction port diameter: 2” G-M
• Discharge port diameter: 2” G-M
• Installation length: 250 mm
• Height: 250 mm
• Length: 386 mm
• Width: 174 mm
• Application: Heating systems, hot water circulation, air conditioning systems, boiler rooms and collective HVAC lines
