109640620 DAB Active Driver Plus T/T 3.0 is a variable-speed controller designed for three-phase electric pump systems. It maintains constant pressure, ensures energy efficiency, and automatically regulates the pump’s performance. The integrated sensors provide protection from dry running, overheating, and voltage fluctuations. Easy to install and ideal for both residential and industrial use.

Technical Specifications:
Model: T/T 3.0
Line voltage: 115V and 230V single-phase, 400V three-phase
Electric pump voltage: 115V and 230V single-phase, 230V and 400V three-phase
Power supply frequency: 50–60 Hz
Installation: Vertical or horizontal (for M/M and M/T models)
Max liquid temperature: 50°C
Max operating temperature: 60°C
Max flow rate: 15 m³/h
Max pressure: 13 bar
Pressure regulation range: 1–13 bar
Suction diameter (DNA): 1 1/4” male
Delivery diameter (DNM): 1 1/2” female
Protection level: IP55
Special protection: Against dry running, overcurrent, overheating, and voltage variations
